108-75 broken bridge sliding window

Profile wall thickness	1.4mm±0.1
Profile width	Box: 108 mm / fan: 75 mm
Standard hardware	Oz, Germany
Heat insulating tape	PA66 nylon tape
Glass standard	5+9A+5
King Kong gauze net	Diameter 0.8mm 304 stainless steel material ±0.1

Performance Parameter:

Thermal insulation performance	3.7 (w/m².k)
Sound insulation performance	35dB
Watertight performance	Level 6
Airtight performance	Level 8
Resistance to wind pressure	Level 9 / 5000PA

About Konya

· The use of high-grade villa special aluminum alloy design, ultra-high strength without deformation, can withstand ultra-high wind pressure.
· The door leaf is spliced with a 45-degree angle, which is firm, safe, beautiful and generous.
· Push and pull is lighter and smoother, equipped with fine car craft pulleys capable of bearing up to 100KG, pulleys made of POM material, with higher strength and wear resistance, so that doors and windows push and pull conveniently, smoothly, open more flexibly, and there is no damage for up to 100000 times.
